Meridian M20L Green Laser GNSS RTK is an innovative solution that combines advanced laser technology IMU, and 4G integration. It is calibration-free, significantly boosting operational efficiency and laser measuring makes the rodless survey improve efficiency and reduce risk factors. The M20L green laser receiver provides a new way to work in challenging & impossible& dangerous scenarios with high accuracy, including riverine stake-out, bridge pile surveying, elevation surveying, municipal surveying, outdoor & indoor combination surveying, and power station surveying, ect.
Laser technology offers unparalleled advantages in precision positioning and makes surveying work rodless and Easier. Combining cutting-edge 100m range laser technology with full constellation GNSS, IMU, and 4G integration, delivers calibration-free accuracy, significantly enhancing work efficiency and reducing potential risks.
Equipped with laser & 120° calibration-free IMU technology in a small body, it complements the laser's outstanding performance, extend- ing the M20L's application range to locations that traditional RTK systems cannot reach, opening up new horizons for product applica- tions, enhancing customer satisfaction and boosting operational effi- ciency.
With 7.4V 7000mah and the quick-charge capability, sup- ports you in working more than 26hours and greatly saves your time.
The palm-sized RTK (Real-Time Kinematic) system combines elegance with precision, offering a compact solution for accurate positioning on-the-go.
With 7.4V 7000mah and the quick-charge capability, supports you in working more than 26 hours and greatly saves your time.
It supports BDS, GPS, GLONASS, Galileo, QZSS, SBAS, and L-Band. Its 1760 channels offer comprehensive GNSS signal tracking capability.
| Channel | 1760 (1980 option) |
| BDS | B1I，B2I，B3I，B1C，B2a，B2b* |
| GPS | L1 C/A，L1C，L2P(Y)，L2C，L5 |
| GLONASS | L1，L2，L3* |
| GALILEO | E1，E5a，E5b，E6* |
| QZSS | L1C/A, L1,L2, L5,L6* |
| SBAS | L1, L5* |
| NavIC(IRNSS)* | L5 |
| L-band | B2b PPP (Only for the Asian-Pacific Region)& HAS* |
| Data Format | CMR, CMR+, RTCM2.X, RTCM3.X |
| Data Output | NMEA-0183, RINEX, TXT |
| Data Updating Rate | Up to 20Hz |
| Time to Recapture | <1s |
| Cold Start | <40s |
| Single Point Positioning (RMS) | Horizontal: 1.5m | Vertical: 3.0m |
| DGPS (RMS) | Horizontal: 0.4m | Vertical: 0.8m |
| Real-Time Kinematic (RMS) | Horizontal: ±(8mm+1ppm) |
| Speed Accuracy (RMS) | 0.03m/s |
| Static Accuracy (RMS) | Horizontal: ± (2.5mm+0.5ppm) |
| Time Accuracy (RMS) | 20ns |
| Speed Accuracy | ≥0.03m/s |
| Tilt Compensation Accuracy | ≤2cm(Tilt Angle≤60°, Up to 120°) |
| IMU Update Frequency | 200Hz |
| Laser Accuracy (RMS) | Horizontal: ±(8mm+3mm/m) |
| Bluetooth | SPP3 0+BLE5 0 Dual Mode, 2.4 GHz @ +6 dBm |
| WiFi (option) | 802.11 a/b/g/n/ac |
| Cellular | LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28 |
| Storage | 32GB |
| Internal Radio | Transmitting Power: 2W(33±1dBm) 1W(30±1dBm) |
| Specifications | 7.4V,7000mAh lithium ion Rechargeable Battery |
| Operating Times | RTK base/rover mode: up to 20 hours, RTK laser/AR: up to 15 hours |
| Charging | Support USB PD 15V/2A (Supports Quick Charging Adapter) |
| Operating Temperature | -40°C~+85°C |
| Storage Temperature | -55°C~+85°C |
| Anti-seismic | 2m Pole Drop Onto Concrete |
| Dust & waterproof | IP68 |
| AR Camera | 12MP large viewing angle, for live view stakeout |
| I/O Interface | 1× USB type-C port; 1 × TNC antenna port; 1× SIM cardslot; 1 × 5 pin LEMO port |
| Dimensions | 125mm×125mm×79mm |
| Weight | ≤699g |
* Specifications may vary by configuration. Please confirm with our team before ordering.
